Cub Cadet ULTIMA ZT1 42 17TREACS010

Description

SET UP AND PREP FEES MAY APPLY

FACTORY MODEL: 17TREACS010, 17AREACSA10
ULTIMA ZT1 42

• A 22 HP/725cc Kohler 7000 twin-cylinder OHV engine delivers high-performance power to tackle your yard
• Dual hydrostatic transmissions allow for quick and effortless 7 MPH forward (3.5 MPH reverse) ground speeds that leaves your lawn with a professional-quality finish
• A continuous square 2 in. x 2 in. tubular steel frame with fully e-coat lower frame and triple guard corrosion defense system, a multi-step process that electronically applies automotive-grade corrosion resistance with meticulous care to protect against wear and tear

• 42-in. steel cutting deck with smooth arc dual-blades, cut overlap and deep dome deck design provides flawless results, mows a wide area of grass to help reduce cutting time, is rust-resistant and provides your lawn with a clean-cut look

Engine

• Engine: Kohler KT725-3083
• Engine Displacement:  725cc
• Engine Output:  22 HP
• Fuel Tank Capacity:  3.5 Gallon fuel tank capacity to keep you mowing and minimize time loss for refueling needs
• Battery: 210 cca AGM

Drive System

• Transmission:  Dual Hydro-Gear™ EZT-2200™
• Forward Speed:  7 mph
• Reverse Speed:  3.5 mph
•

Cutting Deck

• Deck Cutting Width:  42″
• Deck Wash:  SmartJet deck wash system provides high pressure water that cleans out grass and debris build-up under the deck
• Deck Material:  13-gauge stamped steel
• Deck Engagement (PTO):  Electronic fingertip blade engagement
• Spindle Construction:  Sealed cast aluminum housing (maintenance-free)
• Blade(s):  Twin Blades
• Cutting Height Range:  1” – 4.5” leads to a precise even cut
• Deck Positions:  Foot pedal with spring assist creates the perfect cut | 15 Positions
•

Chassis

• Frame: 2” x 2” tubular steel frame with fully E-Coat lower frame and Triple Guard Corrosion Defense System™
• Front Axle(s):  Fixed 2″ x 2.5″ fully welded tubular steel axle (e-coated)
• Turning Radius:  Zero degrees
• Front Tires:  11″x 6″-5″
• Rear Tires:  20”x8”-8″
• Tire Tread:  Turf Master
• Bumper:  2″ x 2″ Tubular steel bumper
• Rear Tow Hitch:  Standard
• Corrosion Protection:  Triple Guard Corrosion Defense System™
• Yokes:  1/4″ steel yokes provide greater durability
•

Controls

• Cruise Control:  N/A
• Handle Grip(s):  Ergonomic lap bar
• Brakes:  Integrated parking system in lap bars for ease of use
• Steering Wheel Control:  3-way adjustable ergonomic lap bar
• Headlight(s):  Illuminating Dual-LED Headlights provide ultimate vision for mowing in low light conditions
• Mow in Reverse:  Standard
•

Comfort

• Seat Type:  Automotive-inspired, ergonomic, fully adjustable premium 18” high-back seat
• Seat Suspension:  Durable, advanced polymer seat suspension system
•

Dimensions

• Dimensions:  L/W/H 80” x 54” x 47”
• Weight (approx.):  500 lbs.
•

Additional Specifications

• Mulch Kit: Optional
• Model Number:  17TREACS010 OR 17AREACSA10
•  Hour Meter: No
•

Warranty

• Warranty: 3-year / unlimited-hour warranty. limited lifetime warranty on frame. Lifetime limited on deck shell. No commercial warranty

• AIR FILTER:32 883 09-S1 OR 490-200-K054
• OIL FILTER:12 050 01-S
• OIL:  490-000-C044
• FUEL FILTER:25 050 22-S1
• SPARK PLUG:25 132 23-S  RC12YC
• DECK BELT :754P06134 OR 490-501-C081
• DRIVE BELT:  954-04317A OR 490-501-C069
• BLADES: 742P05528
• XTREME BLADES:  742P05177A-X OR 490-110-C202
• IGNITION KEY:925-1745A
• HOUR METER KIT: 490-900-C075
