Description
The true, complete OEM wheel and tire assembly, including the bearings and bushings, to replace Dixie Chopper part number 402091, which now replaces part number 400130.
It has the heavy-duty Carlsile Reliance flat-free, ribbed-tread tire, size 13×6.50-6, with the internal hub components as shown.
Fits most of the following Dixie Chopper models: LT2000, LT2400, LT2700, RB2700, SP2800, X2003, XF2700, XG2703, XT3200, XWF2700, and XWF3000. Please match part numbers to verify fitment.
*The Bearing Kit Is Included But Not Installed.
Replaces Dixie Chopper Part Numbers:
- Dixie Chopper 402091 (With the bearings & bushings)
- Dixie Chopper 400130 (With the bearings & bushings)
This Dixie Chopper wheel bearing kit includes:
- (1) Part Number 67204 (Inner Front Wheel Spacer)
- (2) Part Number 67205 (Inner Front Wheel Bearings)
- (2) Part Number 10205 (Outer Front Wheel Bearings)
Dimensions:
- Tread: Ribbed
- Tire Type: Flat-Free Carlisle Reliance
- Tire Size: 13×6.50-6
- Hub Length: 3-3/4″ Centered (Length includes bushings installed)
- Rim/Hub ID Without Bearings: 1-3/8″
- Final Bore With Bearings (ID): 5/8″
Have a question about this product? Contact us for assistance and tell us you are looking at SKU 10915-9719 ( A-B1FP104 & A-B1DC49).
